Did you know Max Built Trailers offers custom-built trailers? In order to ensure a speedy manufacturing process, we need you to gather the necessary information and consider several factors to make sure that the trailer meets your specific requirements and preferences. Here’s what you need to know to get a custom built trailer:
What is the purpose and functionality of the custom trailer?
Determine the primary purpose of the trailer and how you intend to use it. Whether it’s for hauling equipment, transporting goods or recreational activities, understanding the intended use will help guide the customization process.
Consider some of the most popular items that are commonly hauled with trailers, including:
- Construction equipment and materials
- Landscaping supplies and machinery
- Recreational vehicles (ATVs, motorcycles, boats)
- Household goods and furniture
- Livestock and agricultural products
- Automotive vehicles (cars, trucks, dirt bikes, motorcycles)
What payload capacity will the custom trailer need?
Calculate the maximum weight of the cargo you plan to haul to determine the required payload capacity of the trailer. Consider factors such as the weight of the items being transported and any additional equipment or accessories that will be onboard. Our custom trailers can be designed to haul cargo ranging from cars and trucks to ATVs, heavy machinery and more.
| Type of Trailer | Empty Weight (est.) | Typical GVWR (loaded) | Typical Tongue Weight (loaded) |
| Canoe/Kayak Trailer | 100 to 400 pounds | 200 to 800 pounds | 30 to 120 pounds |
| Motorcycle Trailer | 100 to 600 pounds | 800 to 3,000 pounds | 120 to 450 pounds |
| Trailer or Dolly for Towing Car | 400 to 800 pounds | 3,000 to 5,000 pounds | 450 to 750 pounds |
| Utility or Equipment Trailer | 400 to 1,200 pounds | 2,000 to 7,000 pounds | 300 to 1,050 pounds |
| Pop-Up Camper | 1,500 to 3,200 pounds | 2,800 to 4,300 pounds | 420 to 645 pounds |
| Large Travel Trailer | 5,000 to 9,000 pounds | 6,500 to 11,000 pounds | 975 to 1,650 pounds |
| Fifth-Wheel Camper | 5,000 to 15,000 pounds | 17,000 to 20,000 pounds | 2,550 to 3,000 pounds |
What are the Custom Trailer Size and Dimensions?
Determine the appropriate size and dimensions of the trailer based on the type and quantity of items you want to transport. Consider factors such as length, width and height requirements to accommodate the cargo appropriately.
Also, the type of vehicle you drive will play a factor.
Popular full size trucks towing capacity:
| Pickup Truck | Towing Capacity |
| 2024 Ford F-150 | Up to 14,000 lbs. |
| 2024 Chevy Silverado 1500 | Up to 13,300 lbs. |
| 2024 GMC Sierra 1500 | Up to 13,300 lbs. |
| 2024 Ram 1500 | Up to 12,750 lbs. |
| 2024 Toyota Tundra | Up to 12,000 lbs. |
Popular mid size vehicles towing capacity.
| Vehicle | Towing Capacity | Payload capacity |
| Ford Maverick | 2,000 to 4,000 lbs | Up to 1,500 lbs. |
| Toyota Tacoma | 6,400 – 6,500 lbs | 1,096 – 1,285 lb |
| Ford Ranger | Up to 7,500 lbs | 1,430 – 1,650 lbs |
| Jeep Gladiator | 4,000 – 7,700 lbs | 1,075 – 1,710 lbs |
| Chevrolet Colorado | 3,500 – 7,700 lbs | 1,367 – 1,550 lbs |
| GMC Canyon | 3,500 – 7,700 lbs | 1,398 – 1,578 lbs |
| Honda Ridgeline | 5,000 lbs | 1,486 – 1,530 lbs |
What type of trailer do you want to customize?
Max Built Trailers offers nine different kinds of trailers, so you just need to decide which type best suits your needs based on size of your load. Below are the following trailers we specialize in that can be custom built:
- Aluminum Trailers
- Car Trailers
- Deckover Trailers
- Dump Trailers
- Enclosed Trailers
- Equipment Trailers
- Gooseneck Trailers
- Tilt Trailers
- Utility Trailers
What kind of materials do you want?
Consider the materials and construction methods used in building the trailer. Determine whether you prefer aluminum or steel construction—as well as the overall durability and quality of the materials used.
What options and features do you want for your custom trailer?
Identify any specific customization options you require, such as additional tie-down points, storage compartments, ramps, hitches or electrical wiring for lighting and accessories.
What is your budget?
No matter your budget, we can work with you on a custom-built trailer project. We are careful to take into account the cost of materials, labor and any additional features or accessories and communicate what these are. Be prepared to discuss your budget with the manufacturer to make sure the trailer design aligns with your financial constraints. The entire custom trailer fabrication process is transparent and your satisfaction is guaranteed!
Local licensing and regulations
You don’t want to overlook the law and find yourself pulled over by a state trooper. Familiarize yourself with local regulations and requirements for towing trailers—including licensing, registration and towing capacity restrictions. Ensure that the custom-built trailer complies with all applicable safety standards and regulations.
By considering these factors and gathering relevant information beforehand, you’ll be better prepared to communicate your needs and preferences to us and ensure that a Max Built Trailers custom-built trailer meets your expectations.
Contact us now to start the process!
